L3 PoE+ Managed Switch
48x10/100/1000Mbps RJ45 Access Ports
4x1/10G SFP+ Uplink Ports
Upto 176 Gbps Switching Capacity
Upto 130.94 MPPS Full-Duplex Throughput
1x Console Port
1x RJ45 Management Port
OSPFv2/v3
RIPv1/v2
IPv4/IPv6 Static Routes
Inter VLAN
DHCP Server, Relay and client
VLAN - MAC Based, Protocol Based, Voice VLAN, Private VLANs
L2 Loop Avoidance (STP/RSTP/MSTP)
ERPS (ITU G.8032)
IGMP v1/v2/v3 Snooping
802.1q and QinQ
QoS - Classification, Marking, Policing, and Shaping
0⁰C to +55⁰C Operating Temperature
1U Rack Mountable
Integrated Single AC Power Supply (100-240 VAC)
PoE Budget - 740W
Per Port PoE Configuration and Scheduling
Persistent PoE and Power Delay (to let the Device Boot)
Auto PoE Check and Reboot if Device does not Respond
TACACS+ / RADIUS AAA
DHCP snooping, Dynamic ARP Inspection
Port Security, Sticky MAC, IP-MAC Binding
L2/L3/L4 ACL with Extended Features
WEB GUI, CLI
SNMPv3, RMON, sFlow
Dual Stack (IPv4 and IPv6) Management
Ethernet OAM 802.3ah (CFM)
PoE+ L3 Managed Switch
48 Gigabit Ethernet Access Port
4x1/10G SFP+ Uplink Ports
Upto 176 Gbps Switching Capacity
Upto 130.94 MPPS Full-Duplex Throughput
1x Console Port
1x RJ45 Management Port
Routing Table for IP Address Information
DHCP Server, Relay and Client
RIPv1 / v2 Dynamic Routing
OSPFv2 / v3 Dynamic Routing
Inter-VLAN Routing
MAC Table for MAC Address Information
STP/RSTP, MSTP, ERPS
IGMP v1/v2/v3 snooping
802.1q and QinQ
QoS – Up to eight priority queues
0⁰C to +55⁰C Operating Temperature
1U Rack Mountable
Integrated Single AC Power Supply (100-240 VAC)
PoE Budget - 740W
Per port PoE configuration and scheduling
TACACS+ / RADIUS AAA
DHCP snooping, Dynamic ARP Inspection
Port Security, Sticky MAC, IP-MAC Binding
WEB GUI, CLI
SNMPv3, RMON, sFlow
Dual Stack (IPv4 and IPv6) Management
Ethernet OAM 802.3ah
HSP-IO-24S4XS-C3AH+: Dual Hot Swap Power Supplies (100-240 VAC, -48V DC)
Smart Cities
Delivers reliable and scalable infrastructure for city-wide services, connecting critical systems like surveillance, utilities, and public access points through a centrally managed, secure platform.
Campus Networks
Supports large-scale connectivity across academic blocks, administrative zones, and labs — enabling centralized access control and seamless user mobility throughout the network.
ISPs
Ideal for use at the access or distribution layer, providing consistent and manageable connectivity across customer-facing and service aggregation points in the network.
BFSI
Supports secure and segmented network operations in data centers, branches, and compliance zones — ensuring high availability and control over sensitive financial systems.
