802.11ax
5.1 to 5.9 GHz Frequency Band
2x2 MIMO
Upto 1024 QAM Modulation
2 Gbps Peak Data Throughput
20/40/80/80+80 MHz Channel Width
Upto 24 dBm Tx Power
23/25/27 dBi Integrated Antenna
2x N Type Connectors for External Antenna
1 x 2.5 GbE
IEEE 802.3at, 48V Indoor/Outdoor AC/DC /SFP PoE
6 kV Surge Protection
IP67 Protection
Dynamic Channel Selection (DCS)
Dynamic Data Rate Selection (DDRS)
Automatic Tx Power Control (ATPC)
Automatic Channel Selection (ACS)
Hitless Channel & Modulation Change
Spectrum Analyser
Channel Bonding
4 level Priority QoS
IPv4 / IPv6 Support
QinQ, Trunk, Access, Transparent and Management VLAN
Jumbo Frame up to 9000 Bytes
AES-256
WPA2/3
MAC Based Access Control
Web GUI
CLI
EMS (SNMPv2/v3)
Dying Gasp
GPS
Temperature Sensor
Extended Temperature
Note: Variants can be Combined to Meet Unique Deployment Needs
802.11ax
5.1 to 5.9 GHz Frequency Band
2x2 MIMO
Upto 1024 QAM modulation
2 Gbps Peak Data Throughput
20/40/80/80+80 MHz Channel Width
Upto 24 dBm Tx Power
27/29 dBi Integrated Split Dish Antenna
2x N Type Connectors for External Antenna
1 x 2.5 GbE
IEEE 802.3at, 48V Indoor/Outdoor AC/DC /SFP PoE
6 kV Surge Protection
IP67 Protection
Dynamic Channel Selection (DCS)
Dynamic Data Rate Selection (DDRS)
Automatic Tx Power Control (ATPC)
Automatic Channel Selection (ACS)
Hitless Channel & Modulation change
Spectrum Aanalyser
Channel Bonding
4 level Priority QoS
IPv4 / IPv6 support
QinQ, Trunk, Access, Transparent and Management VLAN
AES-256
WPA2/3
MAC based access control
Web GUI
CLI
EMS (SNMPv2/v3)
Dying Gasp variant
GPS
Temperature sensor variant
Extended temperature variant (Note: variants can be combined to meet unique deployment needs)
Telco
Scalable, high-performance wireless backhaul for rapid 4G/5G network expansion and rural connectivity.
Enterprise
Reliable, point-to-point connectivity delivering secure, high-speed performance for critical applications.
ISPs
Cost-effective, high-capacity backhaul solutions to extend network coverage and improve service quality.
Industries
Robust wireless links with rugged hardware for factory automation, logistics.
